Kayan Smoke Curtains: Advanced Smoke Control That Saves Lives
🔹 Why Smoke Control Is Essential
Many people believe fire are the greatest danger during a fire.
In reality, smoke spreads much faster, reducing visibility, limiting breathing, and making evacuation extremely difficult.
This is why smoke management has become one of the most important parts of modern passive fire protection.
Kayan Smoke Curtains automatically control smoke movement before it fills occupied spaces.
🔗 Learn more:
https://kayancomp.com/
🛡️ What Are Kayan Smoke Curtains?
Kayan Smoke Curtains are automated smoke containment systems designed to deploy automatically once the building fire alarm activates.
Their primary purpose is to channel smoke toward extraction systems while maintaining clear evacuation routes.
They help:
- Control smoke movement
- Improve visibility
- Support smoke ventilation
- Protect escape routes
- Improve firefighter access
🌫️ How Smoke Curtains Work
After alarm activation:
✔ Curtain deploys automatically
✔ Smoke is contained
✔ Smoke is directed toward extraction vents
✔ Escape routes remain clearer
✔ Evacuation becomes safer
The system works together with smoke ventilation and fire alarm systems.
⚙️ Advanced Design
Manufactured using:
- Lightweight fiberglass fabric
- Smoke-resistant coating
- Reinforced stabilization systems
- Motorized automation
Configurations include:
- Vertical
- Horizontal
- Concertina
High-Performance Materials & Technology
Kayan curtains are manufactured using advanced materials:
– High-temperature resistant fiberglass fabric
– Silicone / PU coated for enhanced heat resistance
– Reinforced structural design for durability
– Motorized automatic deployment systems
Engineered to perform under extreme fire conditions.
System Types
Kayan systems are available as:
– Smoke Curtains (tested to UL 1784 – air leakage control)
– Combined Fire & Smoke Curtain Systems
Solutions are selected based on project design and authority requirements.
Performance Highlights
– Air Leakage Performance:
• Maximum allowable: 0.015 m³/s·m² @ 25 Pa (UL 1784)
• Achieved performance: ~0.004 m³/s·m² @ 25 Pa
These values demonstrate high efficiency in smoke containment and fire protection.
Compliance & International Standards
Kayan Fire & Smoke Curtains are independently tested in accordance with internationally recognized standards:
– UL 10D – Fire Tests of Fire-Protective Curtain Assemblies
– UL 1784 – Air Leakage (Smoke Control Performance)
– SASO / Saudi Standards
Designed to comply with:
– Saudi Building Code (SBC)
– NFPA 80 & NFPA 105 requirements
💡 Why Choose Kayan Smoke Curtains?
✔ Intelligent smoke control
✔ Faster evacuation
✔ Better visibility
✔ Hidden installation
✔ Reliable automation
✔ Modern architectural integration
