Kayan Smoke & Fire Curtains: Smart Protection Beyond Traditional Fire Barriers
🔹 Why Modern Buildings Need Intelligent Curtain Systems
Modern buildings are becoming larger, more open, and more architecturally complex.
Traditional fire walls and rigid barriers are no longer practical for spaces such as atriums, airports, shopping centres, hotels, and transport hubs.
At the same time, smoke remains the leading cause of fire-related fatalities, often spreading faster than flames themselves.
This is why Kayan Smoke & Fire Curtains have become an essential component in advanced fire protection strategies.
🔗 Discover integrated fire safety solutions:
https://kayancomp.com/
🛡️ What Are Kayan Smoke & Fire Curtains?
Kayan Smoke & Fire Curtains are automated passive fire protection systems designed to deploy during emergencies.
Stored discreetly inside ceilings, they activate automatically once fire alarm systems detect smoke or fire.
Their purpose is to:
- Control smoke movement
- Compartmentalize fire zones
- Protect evacuation routes
- Improve visibility during emergencies
- Support safer evacuation procedures
Unlike traditional barriers, these systems remain hidden until needed.
⚙️ How Smoke & Fire Curtains Work
Kayan systems are connected directly to fire alarm systems and smoke detection devices.
When danger is detected:
- Curtains deploy automatically
- Smoke is directed toward extraction vents
- Fire zones become compartmentalized
- Escape routes remain protected
- Visibility is improved for evacuation
Gravity fail-safe systems ensure operation even during power failure.
🔗 Explore fire alarm systems integration:
https://kayancomp.com/fire-alarm-systems/
🔗 Discover firefighting solutions:
https://kayancomp.com/firefighting-systems/
🧵 Advanced Materials & System Design
Kayan Smoke & Fire Curtains are designed using advanced materials engineered for high-risk fire environments.
Materials Include:
- Lightweight fiberglass fabric
- Smoke-resistant coatings
- Fire-resistant silicone / PU coatings
- Reinforced bottom bar systems
- Stainless-steel stitched seams
Available Configurations:
- Vertical curtains
- Horizontal curtains
- Concertina curtain systems
These systems are designed for discreet installation inside ceilings and wall voids for seamless integration into modern architecture.
🔥 High-Performance Protection
Kayan systems deliver advanced smoke control and fire resistance performance.
Performance Specifications:
- Fire Curtains (tested to UL 10D – up to 180 minutes fire resistance)
- Smoke Curtains (tested to UL 1784 – air leakage control)
- Combined Fire & Smoke Curtain Systems
- Radiation and heat control performance
- High-temperature resistance for critical situations
📊 Performance Highlights:
– Fire Resistance Rating: Up to 180 Minutes (UL 10D)
– Air Leakage Performance:
• Maximum allowable: 0.015 m³/s·m² @ 25 Pa (UL 1784)
• Achieved performance: ~0.004 m³/s·m² @ 25 Pa
🏗️ Applications
Kayan Smoke & Fire Curtains are ideal for:
- Shopping malls
- Airports & transportation hubs
- Hotels & leisure complexes
- Stairwells & lift lobbies
- Escalators & corridors
- Reception areas
- Open-plan offices
- Museums
- Large internal openings
🧪 Compliance & International Standards
Kayan Smoke & Fire Curtains are independently tested according to internationally recognized standards:
- UL 10D – Fire Protective Curtain Assemblies
- UL 1784 – Smoke Leakage Performance
- EN 1634-1 – Fire Resistance Testing
- BS EN 12101-1 – Smoke Control Systems
- BS EN 13501-2 – Fire Classification Standards
Designed to comply with:
- NFPA 80 & NFPA 105
- International passive fire protection requirements
- Smoke containment regulations
💡 Why Choose Kayan Smoke & Fire Curtains?
✔ Intelligent automated protection
✔ Smoke control and fire compartmentation
✔ Flexible systems for modern architecture
✔ Reliable fail-safe deployment
✔ Large opening protection
✔ Seamless integration with fire alarm systems
Kayan Smoke & Fire Curtains provide advanced life-safety protection for modern commercial buildings.
